| Pos. | Part No | Qty | Parts name |
|---|---|---|---|
| 9253685 | [1] | PUMP;REGULATOR | |
| 9260887 | [1] | PUMP;REGULATOR | |
| 01 | 1011209 | [1] | CASING |
| 02 | 4179155 | [1] | SLEEVE |
| 03 | 4179156 | [1] | SPOOL |
| 05 | 4375722 | [1] | CYL.;LOAD |
| 06 | 4360590 | [1] | PISTON |
| 07 | 4150302 | [1] | O-RING |
| 08 | 4085607 | [1] | RING;BACK-UP |
| 09 | 4297380 | [1] | O-RING |
| 10 | 4616531 | [1] | SPRING;COMPRES. |
| 12 | 4179161 | [2] | STOPPER |
| 13 | 4368619 | [1] | STOPPER |
| 14 | 4342843 | [3] | O-RING |
| 15 | 4342841 | [2] | O-RING |
| 16 | 4068898 | [2] | NUT |
| 17 | M500807 | [2] | NUT |
| 18 | 4616533 | [1] | SPRING;COMPRES. |
| 20 | 4179171 | [1] | PISTON |
| 21 | 4179170 | [1] | CYL. |
| 23 | 4347107 | [1] | STOPPER;INNER |
| 24 | 4623446 | [1] | SPRING;COMPRES. |
| 27 | 4346522 | [1] | SLEEVE |
| 28 | 4346521 | [1] | SPOOL |
| 33 | 4265964 | [1] | SCREW;SET |
| 34 | J950010 | [1] | NUT |
| 35 | 3103629 | [1] | COVER;REAR |
| 36 | 4611012 | [1] | PISTON |
| 37 | M340820 | [8] | BOLT;SOCKET |
| 39 | 4433327 | [1] | COVER |
| 40 | 4179174 | [1] | PLUG |
| 41 | 4342846 | [1] | O-RING |
| 43 | M341056 | [4] | BOLT;SOCKET |
| 48 | 9134110 | [1] | PLUG |
| 48A | 957366 | [1] | O-RING |
| 100 | 4471488 | [1] | KIT;SEAL |
